Nishant Rana

Workstreams Overview – part 1 – Dynamics 365 Customer Service / Omnichannel

Workstreams can be defined as records or settings, where we can set up the channel, and define routing rules, work distribution, and bots to route work items to the appropriate queue/agents.

Workstream can be of 3 different types – Messaging, Record, and Voice.

For Messaging we can specify the below channels – Apple messages for business, Chat, Custom, Facebook, Google’s Business Messages, LINE, SMS, Twitter, WeChat, and WhatsApp.

For Messaging Type as Channel, we can specify Work Distribution Mode as either Push or Pick.

We also need to specify a Fallback Queue, this Queue will be used if no matching queues are found based on the routing rules.

In the case of the Chat channel, we have the option of making chats persistent, so any new messages from the customer will be routed to the same queue and same agent if available or the next best agent.

For all other channel types, we have the same Work Distribution mode and Fallback queue option.

For the workstream type as Record, we can select the entities with queues enabled. The remaining option of work distribution mode and fallback queue remains the same.

For the record routing to work, we need to make sure Unified Routing is switched on in the environment.

And the entity is enabled for record routing.

For the workstream type as Voice, we have the voice channel selected as default and disabled.

The only difference is in the distribution mode, where we do not have the option of Pick.

In a nutshell –

Workstream Type	Channel	Additional Information
Messaging	Apple Message for Business, Chat, Custom, Facebook, Google’s Business Messages, LINE, Microsoft Teams, SMS, Twitter, WeChat, WhatsApp	For Chat, we have an additional option to make chats persistent. https://learn.microsoft.com/en-us/dynamics365/customer-service/persistent-chat Push and Pick – Work distribution mode.
Record	Entities With Queue and Record Routing enabled	Push and Pick – Work distribution mode
Voice	Voice Call (default / disabled)	Only Push distribution mode.

In coming blog posts we’d delve deep into the workstreams configuration.

Hope it helps..

Advertisements

How to – Provision / Setup Omnichannel for Customer Service trial – Dynamics 365

In this post, we’d start by creating a trial of Dynamics 365 Customer
Service.

Navigate to – https://dynamics.microsoft.com/en-us/customer-service/overview/

And select Try for free

Enter your email details and follow the steps.

In a few mins, the trial will be ready.

Clicking on Launch Trial opens the Customer Service Workspace app.

Below are the other apps we can see installed as part of the Customer Service Trial, including the Omnichannel Admin Center and Omnichannel for Customer Service along with the Customer Service admin center app.

Opening the Omnichannel Admin Center app allows us to configure the Chat Demo.

In a few seconds, the demo will be configured.

Clicking on the Open agent app opens the Omnichannel for Customer Service App.

Click on Let’s Chat! widget to start the chat.

Opening the Let’s Chat widget sends the notification to the agent as shown below.

Clicking on Accept in the notification starts a new session.

It also starts the conversation.

The agent can click on End or the customer can close the Chat Widget to end the conversation

The End button is grayed out and the customer gets the message as Agent has ended the conversation.

As we can see, we have the working Omnichannel trial environment ready for us to try out different channels/features, etc.

In Power Platform Admin Center, if we check inside Resources >> Dynamics 365 Apps for the Customer Service Trial we can see the Omnichannel Apps installed.

Interestingly if we navigate to Resources >> Dynamics 365 apps and check the Omnichannel for Customer Service app we see the status Not configured.

Clicking on the Manage option, opens the dialog box, informing us that it will navigate us to Dynamics 365 apps admin page.

In our case it kept us asking to sign in, instead of taking us to the admin page.

So next we tried Providing the data access consent as mentioned in the MS Docs.

https://learn.microsoft.com/en-us/dynamics365/customer-service/omnichannel-provision-license#provide-data-access-consent

For which we got the below error.

As it failed, we tried the same after assigning the Power BI (free) license to the admin user. (The user should also have Microsoft 365 Global Admin roles along with System Administrator in the env.)

https://learn.microsoft.com/en-us/dynamics365/customer-service/try-channels

https://learn.microsoft.com/en-us/dynamics365/customer-service/omnichannel-provision-license#prerequisites

And it worked this time.

This time clicking on Manage for the Omnichannel for Customer Service, took us to the Dynamics 365 Admin page.

Inside Dynamics 365 Administration Center we can manage the environments in which we want to install or remove the Omnichannel as well as different channels inside it.

From the Admin Center, we managed to upgrade the Omnichannel in the Customer Service Trial environment and also configure it in another sandbox environment.

Interestingly even after the update/setup was completed

the status of Omnichannel for Customer Service on the Dynamics 365 Page was “Not configured”, which could be some bug or something as mentioned in the MS Docs.

https://learn.microsoft.com/en-us/dynamics365/customer-service/omnichannel-provision-license#set-up-omnichannel-for-customer-service-

“You can safely ignore the status”

So in our case, when we had configured the Customer Service Trial, the Omnichannel was already configured in that environment as we saw earlier. We were mainly facing issues to access the Dynamics 365 Administration Center, which got resolved after assigning the Power BI License to the admin user followed by giving the required consent.

Kindly refer to the below links to learn about Omnichannel in in-depth

https://neilparkhurst.com/2022/08/11/omnichannel-for-customer-service-collection-2/

https://thecrm.ninja/omnichannel-for-dynamics-365/

https://www.youtube.com/watch?v=WM2JLGNPzT8

Hope this helps..

Advertisements

How to – Connect to Exchange Online to get mailbox details (PowerShell)

Recently we were trying to figure out a few details about the user’s mailbox.

To get the details –

Open Windows PowerShell with the “Run as Administrator” option.

Install the Exchange Online Module – Install-Module -Name ExchangeOnlineManagement
Import the Exchange Online Module cmdlets – Import-Module ExchangeOnlineManagement
Connect to Exchange Online using the administrator account – Connect-ExchangeOnline

To get a summary of the all mailboxes in the organization – Get-Mailbox -ResultSize unlimited

To get specific mailbox details – Get-Mailbox -Identity “user1@2022rw1.onmicrosoft.com”

To get the complete detail of a mailbox – Get-Mailbox -Identity user1@2022RW1.onmicrosoft.com | Format-List

Get all the details here – https://learn.microsoft.com/en-us/powershell/module/exchange/get-mailbox?view=exchange-ps

Hope it helps..

Advertisements

{Hidden Gem}Understanding Server Side sync Performance Dashboard

https://learn.microsoft.com/en-us/power-platform/admin/troubleshooting-monitoring-server-side-synchronization#the-server-side-synchronization-monitoring-dashboard

https://learn.microsoft.com/en-us/power-platform/admin/orgdborgsettings?source=recommendations

MSDYNAMICSBLOG BY DEEPESH

In my previous post, I shared Step by Step guide to configure Server side sync:

{Step by Step} Set up server side sync with CRM 2015 Update 1 Online and Office 365

This post is a logical extension to analyse Server side Sync performance using out of box tools.

Lot of times, People report issues on Server side synchronization for one particular mailbox or set of mailboxes.

First thing, in such scenarios should be to check out of box available Server side performance dashboard:

The first screen gives useful information on the mailboxes with hyperlinks, clicking them can directly take you to the intended mailboxes:

The second graph describes Mailbox processing history with Success/Failiures:

Third graph points to processing times:

Error codes (Top 5 are displayed) in the fourth graph:

CRM Items waiting to be traced can be found in fifth graph:

Last graph displays items processed or failed:

Hope…

View original post 14 more words

Improve fetch xml performance by using latematerialize option.

Late Materialize – https://docs.microsoft.com/en-us/power-apps/developer/data-platform/fetchxml-performance

Passion Dynamics

If you have been working on dynamics projects, I bet fetch xml is your best friend as it’s really an easiest way to query and execute in order to get required results. Along with that, constructing it in advanced find is super easy too.

Don’t forget about amazing XRM toolboxes which helps you creating even complex fetch xml queries.

It all sounds fun and easy till your fetch XML becomes really heavy with so many joins or you have a requirement where you need to make many joins.

A Quick tip!
You can have a maximum of 10 joins in fetch xml for dynamics CE.

You will notice that retrieval from dynamics is getting slower and slower as fetch xml becomes complicated. I have faced something similar multiple times. What I did?

well, there are multiple options one of which I want to cover today as using this option, there…

View original post 134 more words

How to – Clone a record in Dataverse / Dynamics 365 (C#)

Here we will be cloning the below contact record –

For it, we can make use Clone method of EntityExtensions class

If we run the below code, we will get the “Cannot insert duplicate key” exception.

Because we need to set the ID for the newly cloned record to either empty or a new GUID.

Also, we need to remove the contactid attribute or entity’s id field else we will get the below exception – “Entity Id must be the same as the value set in property bag“

Also if we are retrieving all the attributes we need to make sure we remove those attribute which can cause below unique constraint errors.

Sql error: The operation attempted to insert a duplicate value for an attribute with a unique constraint. CRM ErrorCode: -2147012606 Sql ErrorCode: -2146232060 Sql Number: 2627

In case of contact, we had to remove the address id attributes, to get the record cloned.

Now let us clone the same contact record with its related leads.

Here first we need to retrieve contact along with its associated lead record.
Then remove the id attribute that could duplicate issues in the child lead records also.

Please refer the helpful posts –

https://debajmecrm.com/clone-record-dynamics-crm-clone-method/

https://www.inogic.com/blog/2014/08/clone-records-in-dynamics-crm/

https://dyncrmexp.com/2017/10/24/retrieve-primary-entities-along-with-related-entities-with-one-queryexpression/comment-page-1/

https://dynamict.eu/2016/08/09/create-record-with-related-records-in-a-single-request-using-c/

Hope it helps..

 // related lead records of contact
                    QueryExpression query = new QueryExpression("lead");
                    query.ColumnSet = new ColumnSet(true);

                    // contact and lead - 1 - n relationship
                    Relationship relationship = new Relationship("lead_parent_contact");
                    relationship.PrimaryEntityRole = EntityRole.Referenced;

                    RelationshipQueryCollection relatedEntity = new RelationshipQueryCollection();
                    relatedEntity.Add(relationship, query);

                    RetrieveRequest request = new RetrieveRequest();
                    request.RelatedEntitiesQuery = relatedEntity;
                    request.ColumnSet = new ColumnSet(true);
                    request.Target = new EntityReference("contact", new Guid("ca0aa844-57c6-ec11-a7b6-00224826af1e"));

                    RetrieveResponse response = (RetrieveResponse)svc.Execute(request);
                    var contactToBeCloned = response.Entity;
                    var clonedContact = contactToBeCloned.Clone(true);

                    // remove attribute that can cause error from main entity
                    clonedContact.Id = Guid.NewGuid();
                    clonedContact.Attributes.Remove("contactid");
                    clonedContact.Attributes.Remove("address1_addressid");
                    clonedContact.Attributes.Remove("address2_addressid");
                    clonedContact.Attributes.Remove("address3_addressid");

                    // remove attribute that can cause error from child / related entities
                    foreach (var relatedEntities in clonedContact.RelatedEntities)
                    {
                        foreach(var leadEntity in relatedEntities.Value.Entities)
                        {
                            leadEntity.Id = Guid.NewGuid();
                            leadEntity.Attributes.Remove("leadid");
                            leadEntity.Attributes.Remove("address1_addressid");
                            leadEntity.Attributes.Remove("address2_addressid");
                        }
                    }
                    svc.Create(clonedContact);
