Using Shared Mailbox and Queue in CRM for implementing generic email address in Dynamics 365 and Exchange Online.


Recently, we had a requirement to send email to customers using a generic email address like donotreply@domain.com from Dynamics CRM (& Exchange Online).

The way we can implement this is through Shared Mailbox and Queue in CRM Online.

Log in to the Administration Portal

https://portal.office.com/adminportal/home#/homepage

Select Shared mailboxes

Members can be added to the Shared Mailbox

Now back in CRM assign the email id to a particular queue.

Now sending an email activity with From as Queue and to as one of the user inside CRM.

Open the user’s mail box.

Make sure we have done Test and Enabled Mailbox for the Shared Email Box and have set Incoming and Outgoing Email as Server-Side Synchronization.

Hope it helps..

App not accessible to certain users in Dynamics 365 (CRM)


Recently we created a new App for one our clients and gave permission to appropriate security roles to access those App.

But still some users were not able to access the App.

Eventually we realized the Security Roles (custom one) assigned was not having Read permission on App to access it.

This fixed the issue.

Hope it helps..

System.Security.SecurityException: That assembly does not allow partially trusted callers while using HttpUtility.UrlEncode in CRM


Hi,

We got the below error in one of our Sandboxed Plugins

“System.Security.SecurityException: That assembly does not allow partially trusted callers”.

We realised it was because of using System.Web.HttpUtility class


We replaced it with EscapeDataString method and this fixed the issue.

System.Uri.EscapeDataString()

Helpful thread

https://stackoverflow.com/questions/3840762/how-do-you-urlencode-without-using-system-web

Hope it helps..

Status not getting updated using SetStateRequest in Dynamics 365.


Hi,

We were recently facing issue while trying to update status for Campaign Entity using SetStateRequest in Dynamics 365. The value for were not getting updated.

Eventually we realized that it could be because of SetStateRequest being deprecated now in Dynamics 365 (online).

Updating the code to use UpdateRequest fixed the issue.

Hope it helps..

Dynamics 365 Developer Toolkit – The extension is already installed to all applicable products.


We were getting the below error for projects inside our Dynamics 365 Developer toolkit solution template.

Trying to run the setup brought the following message

The fix was to go to Tools à Extensions and Updates and enable the extension.

Fixed à

Hope it helps..

Sample code to call Action using Web API in CRM


Just sharing a sample code to call an Action through Web API.

Suppose below is our Action with one input parameter.

JavaScript code :-


function CallAction() {

// get the id of the record and remove the curly bracket part
// id will be used in Web API url
var Id = Xrm.Page.data.entity.getId().replace('{', '').replace('}', '');

var serverURL = Xrm.Page.context.getClientUrl();

// pass the id as inpurt parameter
var data = {

"recordid": Id
};

var req = new XMLHttpRequest();

// specify name of the entity, record id and name of the action in the Wen API Url
req.open("POST", serverURL + "/api/data/v8.2/sab_costmanagements(" + Id + ")/Microsoft.Dynamics.CRM.sab_Recalculate", true);

req.setRequestHeader("Accept", "application/json");
req.setRequestHeader("Content-Type", "application/json; charset=utf-8");
req.setRequestHeader("OData-MaxVersion", "4.0");
req.setRequestHeader("OData-Version", "4.0");
req.onreadystatechange = function () {
if (this.readyState == 4 /* complete */) {
req.onreadystatechange = null;
if (this.status == 200) {
var data = JSON.parse(this.response);
alert(data);
} else {
var error = JSON.parse(this.response).error;
alert(error.message);
}
}
};

// send the request with the data for the input parameter
req.send(window.JSON.stringify(data));
}

Basically we need to pass name of the Entity Set with id of the record followed by name of the action appended with Microsoft.Dynamics.CRM.

In case of global action, we just need the Microsoft.Dynamics.CRM.<<ActionName>>.

More details here

https://www.inogic.com/blog/2016/10/execute-the-global-action-using-web-api-in-dynamics-crm/

Hope it helps..

Missing Action (message) in Plugin Registration Tool


Recently we created a new created Action and it twas not showing up in Plugin Registration Tool.

Closing and restarting the Plugin Registration tool fixed it.

Hope it helps..

Filter SubGrid in Dynamics 365 (with New Form Rendering or Turbo Form)


Recently we had a requirement wherein we wanted to see all the child records of a record in a SubGrid .

We had self-referential (hierarchical relationship) enabled for that entity.

Configuring the Sub Grid on the form.

We have also enabled the Editable grid for the Sub Grid.

The JavaScript code


function filterSubGrid()
{
// get the current record's guid
var entityId = Xrm.Page.data.entity.getId();

// refer the subgrid
var testGrid = window.parent.document.getElementById("Test");

if (testGrid == null)
{
setTimeout(function () {filterSubGrid(); }, 2000);
return;
}

// fetch xml code using User operator
var fetchXml = "<fetch distinct='false' no-lock='false' mapping='logical'>" +
"<entity name='new_test' >" +
"<attribute name='new_name' />" +
" <attribute name='new_testname' />" +
"<order attribute='new_name' descending='true' />" +
"<filter type='and'>" +
"<condition attribute='new_testid' operator='under' value='"+entityId+"'"+"/>" +
"</filter>" +
"</entity>" +
"</fetch>";

if (testGrid.control != null)
{
testGrid.control.SetParameter("fetchXml", fetchXml);
testGrid.control.refresh();
}
else
{
setTimeout(filterSubGrid, 500);
}
}

The filtered Sub Grid (editable)

Note :- The JavaScript code is unsupported as we are making use of getElementById instead of Xrm library to access subgrid.

Hope it helps..

Fixing – “We’re sorry. You do not have sufficient permission on the server to load the application” error in Dynamics 365 for Tablet.


Recently while configuring Dynamics 365 for Tablet we got the below error.

“We’re sorry. You do not have sufficient permission on the server to load the application”

After enabling the tracing we got the details of the error.

https://technet.microsoft.com/en-us/library/hh699694.aspx?f=255&MSPPError=-2147217396#BKMK_MoCA_tracing


The user was having a custom security role to which we had to add the permission for the following entities

  • Connection
  • Role
  • Connection role
  • User Dashboard
  • Note etc..

After updating the security roles with all the required permissions, we were able to use the App.

Hope it helps..


Using ILMerge for Plugin in CRM


If we make use of external assembly in our Plugin (sandboxed) we will get the exception of FileNotFound.

So here we can make use of ILMerge which basically merges the assembly referenced and the plugin into a single assembly.

Install the following NuGet Package.

This adds the following files in our Plugin project.

We need to set Copy Local as true for all our referenced assembly that we want to merge with our plugin.

We need to set Copy Local as false for all other assemblies that we do not want to be merged with plugin.

Just build the project and we are done.

The assembly inside Reflector: –

Hope it helps.

Caching Issue in The Portal Connector (TPC)


We had products configured from CRM to E Commerce settings in TPC. However, what we observed that any update that we are making to prices in the product is not reflecting to the end user using the Portal.

We cleared the cache, deleted the product form TPC did full synchronization etc. but still we were getting the same price for the products in the Product List.

In Product List

The price for the product (the same was the value in CRM)

However, for the end user in the portal the value was showing up the old value.

Eventually we ended up cloning up i.e. creating a new Product with exact same details and doing full synchronization inside TPC.

This worked.

Hope it helps..

Change Order Name and Payment Name Prefix in The Portal Connector (TPC)


To update the prefix, go to Administration – Settings

Then to Advanced

Then to Ecommerce settings

Scroll down to the bottom

Hope it helps..

Query CRM from The Portal Connector (TPC) through Saved Queries


Within The Portal Connector we can make use of Saved Queries to define Fetch XML Query.

Once defined we get a REST based URL which can be used from our client side script.

Login to the Portal and go to Saved Queries

Click on Create a Saved Query

Click on Build and create a Fetch XML Query

The fetch xml builder

We can see the parameter added to the query string.

To consume it we can make use of JavaScript widget

Click on Edit and define the JavaScript inside it to call the function

The JavaScript code.


setTimeout(function(){

// get the logged in user's email i.e. contact in CRM

var userEmail=tpc.identity.userEmail;

var resp = $.ajax({
url: "http://abc.crmportalconnector.com/SavedQueryService/Execute/loyaltypointsavedquery/" + userEmail,
async: false,
dataType: "JSON",
}).responseJSON;
if(resp != null && resp.data != null)
{
var lp = resp.data[0].Attributes.new_loyaltypoint;
document.getElementById("lp").innerHTML = lp;
}
}, 1500);

Hope it helps..

Missing Price for Products in The Portal Connector – E Commerce Settings – Dynamics CRM.


Recently we configured products from CRM to e-commerce setting of The Portal Connector and found that the price for the product was missing.

The way to fix this issue is to Open the product form in CRM and add the list price field on the product form and specify the value there.

Once value is specified, go to administration – portal connector configuration and click on Resynchronize to update the product record in the portal.

Once synchronization is done, we can see the values updated in the portal.

Hope it helps..

Configuring CRM Form inside The Portal Connector for Dynamics CRM / Dynamics 365


The Portal Connector makes it easy to quickly setup a portal that interacts with CRM.

Here let us look at a simple example of setting up Lead form in Insert Mode, which creates lead record in CRM.

Open the Dashboard

Go to CRM Entities and click on Create a CRM Entity.

Here we are creating Lead entity.

Once our lead is setup, we’d create the form.

Go to Contents – Forms.

Click on Create a form.

Inside form, first go to Layout and select TPC Form Layout.

Then go to Content tab, and add Form Configuration

Click on Edit inside Form Configuration and specify the Lead entity we just created.

Drag and add two text fields, one we will configure against first name and other with last name.

Do the same for Last Name text box and publish the form.

Next we need to create a Page wherein we’d display this form. Go to Pages and click on Create a page.

We have created a page named Lead.

Drag TPC Form Manager in the page content.

Configure it and specify our newly created My Lead form.

Select Insert Only check box.

Publish the page and test it. Specify the values and click on Submit.

We’d get the following message.

The lead record created in CRM.

Hope it helps..

Fixed – Workflow must be in Published State error while converting Case to Work Order in CRM


Recently, while trying to convert a case to work order we got the below error.

The immediate thought was to check all the workflow associated to work order and case and see if they all are published, which in fact they were.

Then as suggested here

http://ms-crm-2011-beta.blogspot.ae/2016/11/workflow-must-be-in-published-state.html

we deactivated and activated one of our SLA written against the Work Order entity and it fixed the issue.

Hope it helps..

Sample code to upload file to Azure Blob Storage from CRM Online Plugin


Sharing a sample code which we can use to upload files to Azure Blog Storage from within a CRM Online Plugin. Here we’d be making use of the REST API to simplify things (instead of using Windows Azure Storage library) in our Plugin.

First, we will be creating a storage account of type blob storage and a container inside it.

Log in to Azure Portal

https://portal.azure.com

Click on Add to add a new storage account.



Create a new container in it to store the blob files



In Azure Portal – Storage Account, go to Access Keys and copy the key


And also note down the storage account name and container name which will be used to construct the URL.


We can also go to container, select its properties and copy the url.


Here we have written the plugin on Create of Annotation, which then retrieves the attachment and uploads its content to the container.

Let us first see it in action.

We have created a new note and attached a text file to it.


Going back to our portal, we can see the file in our container.


The sample code for the plugin.

using Microsoft.Xrm.Sdk;
using System;
using System.IO;
using System.Net;
using System.Security.Cryptography;
using System.Text;
namespace MyTestPlugin
{

public class UploadFile : IPlugin
{
public void Execute(IServiceProvider serviceProvider)
{
try
{
// Obtain the execution context from the service provider.
IPluginExecutionContext context = (IPluginExecutionContext)serviceProvider.GetService(typeof(IPluginExecutionContext));

// The InputParameters collection contains all the data passed in the message request.
if (context.InputParameters.Contains("Target") && context.InputParameters["Target"] is Entity)
{
// Obtain the target entity from the input parameters.
Entity noteEntity = (Entity)context.InputParameters["Target"];
byte[] doumentBody = Convert.FromBase64String(noteEntity.Attributes["documentbody"].ToString());
string content = Encoding.UTF8.GetString(doumentBody);
string fileName = noteEntity.Attributes["filename"].ToString();

// Upload the attached text file to Azure Blog Container
UploadFileToAzureBlobStorage(content, fileName);

}
}
catch (Exception ex)
{
throw new InvalidPluginExecutionException(ex.Message);
}
}

void UploadFileToAzureBlobStorage(string content, string fileName)
{

string storageKey = "storagekey";
string storageAccount = "storageaccountname";
string containerName = "strogaecontaninername";
string blobName = fileName;

string method = "PUT";
string sampleContent = content;
int contentLength = Encoding.UTF8.GetByteCount(sampleContent);

string requestUri = $"https://{storageAccount}.blob.core.windows.net/{containerName}/{blobName}";

HttpWebRequest request = (HttpWebRequest)WebRequest.Create(requestUri);

string now = DateTime.UtcNow.ToString("R");

request.Method = method;
request.ContentType = "text/plain; charset=UTF-8";
request.ContentLength = contentLength;

request.Headers.Add("x-ms-version", "2015-12-11");
request.Headers.Add("x-ms-date", now);
request.Headers.Add("x-ms-blob-type", "BlockBlob");
request.Headers.Add("Authorization", AuthorizationHeader(method, now, request, storageAccount, storageKey, containerName, blobName));

using (Stream requestStream = request.GetRequestStream())
{
requestStream.Write(Encoding.UTF8.GetBytes(sampleContent), 0, contentLength);
}

using (HttpWebResponse resp = (HttpWebResponse)request.GetResponse())
{
if(resp.StatusCode == HttpStatusCode.OK)
{
// successfully uploaded
}
}

}

public string AuthorizationHeader(string method, string now, HttpWebRequest request, string storageAccount, string storageKey, string containerName, string blobName)
{
string headerResource = $"x-ms-blob-type:BlockBlob\nx-ms-date:{now}\nx-ms-version:2015-12-11";
string urlResource = $"/{storageAccount}/{containerName}/{blobName}";
string stringToSign = $"{method}\n\n\n{request.ContentLength}\n\n{request.ContentType}\n\n\n\n\n\n\n{headerResource}\n{urlResource}";

HMACSHA256 hmac = new HMACSHA256(Convert.FromBase64String(storageKey));
string signature = Convert.ToBase64String(hmac.ComputeHash(Encoding.UTF8.GetBytes(stringToSign)));

String AuthorizationHeader = String.Format("{0} {1}:{2}", "SharedKey", storageAccount, signature);
return AuthorizationHeader;
}
}

}

Hope it helps.

A simple implementation using Azure Functions, Microsoft Flow, Microsoft PowerApps, Dynamics CRM and SendGrid


Let us  implement a simple scenario where we create a lead record in CRM which then talks with Flow (and Power App).

The Flow calls an Azure Function (Custom API) that sends mail to the lead’s email address using SendGrid

1) Let us create an Azure Function that uses SendGrid to send email to the lead’s email address.

Login to Azure Portal and create a new Function App.

https://portal.azure.com

Let us create a Function using Generic Web Hook CSharp template

To keep it simple let us only enable GET method. Go to Integrate tab and in Allowed HTTP Methods Select Selected Methods and check GET.

Also set mode as Standard and Authorization Level as anonymous, which means we do not need a API Key to be passed as query parameter to talk with the function.

Now let us add a new Output

Select SendGrid as the template

Click on Save.

Here we would need to define SendGridApiKey.

Go to SendGrid portal and create a free account over there

https://sendgrid.com

Create and API Key and copy it’s value.

Now go to Application Settings of the Function App and set this key value with SendGridApiKey as the key name.

Now let us go back to our code and update it to work with lead object and Mail class which would be used for sending email using SendGrid API.

Here first we are referring the SendGrid assembly, then getting fullname and email from query string and then creating Mail object.

Save and check the log if the compilation succeeded or not.

Testing our Function.

We can see the mail in the mail box.

This completes our first part.

2) Now let us create the Swagger definition for it which we will use in Power Apps and Microsoft Flows for using this Azure Function as Custom API.

Select our function and click on API definition.

Click on Function.

Update the generated API Definition Template with query parameter details and also test it.

As it is running successfully, click on Export to Power Apps + Flow

This opens up the new section that details the steps we need to follow for using our Azure Function with Power Apps and Microsoft Flow.

There click on Download button.

Click on Go to PowerApps

It opens up the PowerApps portal (asks for log in) and opens the New Connection page.

https://web.powerapps.com

Upload the JSON Definition file for our Azure Function, provide name and description and click on Next.

Click on Create.

Let us quickly test our new connection.

Click on New App in our PowerApps web portal.

Select PowerApps Studio for Web. Let us create a Blank App Phone.

Add a new Data Source and select our Azure Function there.

To get the API Key go to our function and expand API Definition Key.

It works properly.

3) Now let us move to our last step, wherein we use it inside Microsoft Flow and integrate it with Dynamics CRM.

The good thing is to configure the same for Microsoft Flow, we do not have to do any extra step as both Microsoft Flow and PowerApps share the same connection infra.

Go to Microsoft Flow portal

https://flow.microsoft.com/

We can find our Custom API already added there.

Let us create a new flow. Start with Dynamics 365.

When a record is created. Select Organization Name and Leads as the entity and click on Add an Action.

Search for our Custom API.

Select LastName and Email as Dynamic Content from the lead record created.

Click on Create Flow to create the flow.

Unfortunately, we get the below error

Let us go back to our Swagger Definition and update it.

We have updated it as following

Let us quickly test it, import it in Power Apps as new connection and come back to our Flow.

Edit the connection there and specify the API Key as we had done earlier inside Power Apps and update it.

Open Flow and quickly add the required steps and click on Create Flow.

We have successfully created our flow. Now let us test it.

Let us create a new lead record

Our flow runs and sends the mail

That’s it we are done with our simple implementation. The main purpose of this post was to show the integration possibilities which could help us design and implement real world complex scenarios.

Hope it helps..

Calling Azure Functions (GenericWebHook-Csharp) from CRM


In our previous post, we created a simple Azure Function using a free account. (1-hour limitation).

https://nishantrana.me/2017/04/26/starting-with-a-simple-hello-world-azure-functions/

In this post, we’d use our trial Azure account to create a Function App for which we will configure Web Hook trigger and it outputs to Queue and Azure Blog Storage.

We will call this Function from Plugin on Post Create of Lead in CRM Online and pass Lead details to it. This detail will be then passed to Queue and a file inside Azure Blog Storage as Output from the Function.

Open the Azure Portal

https://portal.azure.com

Select Function App.

Create the Function App.

Click on + for Functions to create a new Function.

We’d select GenericWebHook-Csharp template here.

This creates a new Function nme MyLeadWebHook and it has mode set to Webhook and type as Generic JSON.

We can define Post as the only allowed method to call this function as shown below.

Update the code for the function by defining the Lead Object and deserialization logic as shown below.

#r is syntax for referencing the library. Here Newtonsoft.Json library is being referenced for deserialization.

Save and Run to check if it has compiled successfully or not. Click on Test tab to test the function by passing the JSON in the request body.

We can see below that our function has run successfully.

This finishes our Web Hook trigger part. Now let us define the Queue Output to it.

Select Integrate and click on New Output.

Select Azure Queue Storage template here.

Name the queue as leadqueue. This will automatically create a queue name leadqueue.

The parameter name here is outputQueueItem. We will update our code to pass the lead details to this parameter.

Before we update the code for our function let us add new output which saves the Lead details to a text file. Click on new output and select Azure Blog Storage.

Here outputBlob is the parameter to which we need to provide the lead details. In the path outcontainer is the name of the container within Blob and rand-guid generates a random guid for the file name. Here we have added the extension .txt.

Now we have our outputs defined, so let us go back to our code for the function and update it to pass values to both the output parameter one for queue and other for the blob.


#r "Newtonsoft.Json"

using System;
using System.Net;
using Newtonsoft.Json;
public class Lead
{
public string Topic { get; set;}
public string FullName { get; set;}
public string Email { get; set;}
}

public static async Task<object> Run(<span class="hiddenSpellError" pre="" data-mce-bogus="1">HttpRequestMessage</span> req, TraceWriter log, </object>
IAsyncCollector<Lead> outputQueueItem, TextWriter outputBlob)
{
log.Info($"Lead Information Recieved");

string jsonContent = await req.Content.ReadAsStringAsync();
var lead = JsonConvert.DeserializeObject<Lead>(jsonContent);

log.Info($"Lead named {lead.Topic} created for {lead.FullName} with email id {lead.Email}");

// add to queue
await outputQueueItem.AddAsync(lead);

// write to a text file in azure blog storage
outputBlob.WriteLine($"Topic: {lead.Topic}");
outputBlob.WriteLine($"Full Name: {lead.FullName}");
outputBlob.WriteLine($"Email: {lead.Email}");

return req.CreateResponse(HttpStatusCode.OK, new { message = "Lead Information Recieved" });
}

To test the code click on Test and select Run

Click on Monitor tab for the Function and select the log created for our test run. We can see the values for the parameters in the invocation details section.

Now let us write a plugin that runs on Post Create of lead and calls this Function App.

First let us get the URL for our function app. Go to Function and click on Get Function URL.

Our Function URL –

The code parameter is the Key that should be passed while calling the above URL.

Keys tab is where we can configure out Keys.

Below is code for our plugin.


using Microsoft.Xrm.Sdk;
using System;
using System.IO;
using System.Net;
using System.Runtime.Serialization.Json;
using System.Text;

namespace MyTestPlugin
{

public class Lead
{
public string Topic { get; set; }
public string FullName { get; set; }
public string Email { get; set; }
}

public class MyPluginClass : IPlugin
{
public void Execute(IServiceProvider serviceProvider)
{
try
{
// Obtain the execution context from the service provider.
IPluginExecutionContext context = (IPluginExecutionContext)serviceProvider.GetService(typeof(IPluginExecutionContext));

// The InputParameters collection contains all the data passed in the message request.
if (context.InputParameters.Contains("Target") && context.InputParameters["Target"] is Entity)
{
// Obtain the target entity from the input parameters.
Entity entity = (Entity)context.InputParameters["Target"];

using (WebClient client = new WebClient())
{
// get the lead details
var myLead = new Lead();
myLead.Topic = entity.Attributes["subject"].ToString();
myLead.FullName = entity.Attributes["fullname"].ToString();
myLead.Email = entity.Attributes["emailaddress1"].ToString();

DataContractJsonSerializer serializer = new DataContractJsonSerializer(typeof(Lead));
MemoryStream memoryStream = new MemoryStream();
serializer.WriteObject(memoryStream, myLead);
var jsonObject = Encoding.Default.GetString(memoryStream.ToArray());

var webClient = new WebClient();
webClient.Headers[HttpRequestHeader.ContentType] = "application/json";

// our function key
var code = "2QYP6xwCswMNmzJDFJdDE65ed1PdNBOj5Wlu4LbSpeSjs/58h1KLbg==";
// the url for our Azure Function
var serviceUrl = "https://mycrmfunctionapp.azurewebsites.net/api/MyLeadWebHook?code=" + code;

// upload the data using Post mehtod
string response = webClient.UploadString(serviceUrl, jsonObject);
}
}
}
catch (Exception ex)
{
throw new InvalidPluginExecutionException(ex.Message);
}
}
}

}

Let us create our lead record in CRM and test our Azure Function.

We can check the Monitor tab for our Function and check the logs and can see the Lead Information added to queue and also a text file created from our output parameters.

Our text file in the container.

Hope it helps..

Using WebClient to call external service from CRM Online Sandboxed Plugin (HTTP POST and JSON)


Sharing a sample code that can be used to send JSON data using POST to an external service inside CRM Online Plugin. As plugin runs in sandbox mode we cannot reference Newtonsoft’s JSON.NET library http://www.newtonsoft.com/json. The other option could be to use ILMerge, which isn’t that elegant.

Here, basically we are passing some information related to lead to an external service on Post Create of it.


using Microsoft.Xrm.Sdk;
using System;
using System.IO;
using System.Net;
using System.Runtime.Serialization.Json;
using System.Text;

namespace MyTestPlugin
{

 public class Lead
 {
 public string Topic { get; set; }
 public string FullName { get; set; }
 public string Email { get; set; }
 }

 public class MyPluginClass : IPlugin
 {
 public void Execute(IServiceProvider serviceProvider)
 {
 try
 {
 // Obtain the execution context from the service provider.
 IPluginExecutionContext context = (IPluginExecutionContext)serviceProvider.GetService(typeof(IPluginExecutionContext));

 // The InputParameters collection contains all the data passed in the message request.
 if (context.InputParameters.Contains("Target") && context.InputParameters["Target"] is Entity)
 {
 // Obtain the target entity from the input parameters.
 Entity entity = (Entity)context.InputParameters["Target"];

 using (WebClient client = new WebClient())
 {
 var myLead = new Lead();
 myLead.Topic = entity.Attributes["subject"].ToString();
 myLead.FullName = entity.Attributes["fullname"].ToString();
 myLead.Email = entity.Attributes["emailaddress1"].ToString();

 DataContractJsonSerializer serializer = new DataContractJsonSerializer(typeof(Lead));
 MemoryStream memoryStream = new MemoryStream();
 serializer.WriteObject(memoryStream, myLead);
 var jsonObject = Encoding.Default.GetString(memoryStream.ToArray());


 var webClient = new WebClient();
 webClient.Headers[HttpRequestHeader.ContentType] = "application/json";
 var code = "key";
 var serviceUrl = "https://xyz.azurewebsites.net/api/mylead?code=" + code;

 // upload the data using Post mehtod
 string response = webClient.UploadString(serviceUrl, jsonObject);
 }
 }
 }
 catch (Exception ex)
 {
 throw new InvalidPluginExecutionException(ex.Message);
 }
 }
 }
}

Hope it helps..


Integrating Bot with Dynamics CRM (OAuth 2.0 Authentication)


Let us continue with our previous posts on understanding and implementing a simple bot that interact with Dynamics CRM using Microsoft Bot Framework

Till now we had hard coded our connection to CRM inside the bot application which was used to create lead records in CRM.

In this post, we will use OAuth2 authentication to connect to CRM Service (Web API).

We’d update our bot to use Sign-In Card. It will launch a web browser (web site which redirects user to authenticate to office 365) where user will enter the credentials and on successful authentication it will get the authentication token which it would then use to interact with CRM.

Here we would be using Web Site deployed in Azure that takes care of all the plumbing part.

We will be using Bot State Service here for saving Bot State. User can save bot state in this bot state service and can retrieve it. So, we would be passing the user id to the web site hosted to the azure and after we get the authentication token on successful authorization, we save this information in the bot in the bot state using SetUserData method. Back in our Bot app we will retrieve this authentication token saved in session state using GetUserData method and use it for interacting with CRM Web API.

Let us first create a ASP.NET Web Application which would be use for redirecting the user to authentication and saves the authentication token to the Bot State Service.

This creates our Web Application.

Add the following Microsoft.Bot.Builder Nuget Package in the project.


Also add a View named Authorize, which we will use are redirect URI for our Dynamics 365 App that will be registered to Azure Active Directory.


Before we start writing the code in our controller, we need to register dynamics 365 app with Azure Active Directory.

Follow the below post for that.

https://nishantrana.me/2016/11/13/register-a-dynamics-365-app-with-azure-active-directory/

Now we have our required values i.e. client id, client key and end point URL

Add the following keys in web.config.


Here Client Id, Client Secret and EndPoint Url are the one we got when we registered our Dynamics 365 App. Here Microsoft App Id and Password are for our Bot Application.

https://dev.botframework.com

Update the HomeController.cs and add below action methods Login and Authorize.

</p>
using Microsoft.Bot.Connector;
using Microsoft.IdentityModel.Clients.ActiveDirectory;
using System;
using System.Configuration;
using System.Threading.Tasks;
using System.Web.Mvc;

namespace AzureAuthWebApplication.Controllers
{
public class HomeController : Controller
{
public ActionResult Index()
{
return View();
}
public ActionResult Login(string userid)
{
// string userid in session
Session["botuserid"] = userid;
// CRM Url
string Resource = "https://nishutrial.crm.dynamics.com";

AuthenticationContext authContext = new AuthenticationContext(ConfigurationManager.AppSettings["Authority"]);
var authUri = authContext.GetAuthorizationRequestUrlAsync(Resource, ConfigurationManager.AppSettings["ClientId"],
new Uri(ConfigurationManager.AppSettings["RedirectUri"]), UserIdentifier.AnyUser, null);
return Redirect(authUri.Result.ToString());
}

public async Task<ActionResult> Authorize(string code)
{
AuthenticationContext authContext = new AuthenticationContext(ConfigurationManager.AppSettings["Authority"]);
var authResult = await authContext.AcquireTokenByAuthorizationCodeAsync(
code, new Uri(ConfigurationManager.AppSettings["RedirectUri"]),
new ClientCredential(ConfigurationManager.AppSettings["ClientId"],
ConfigurationManager.AppSettings["ClientSecret"]));

// Saving token in Bot State
var botCredentials = new MicrosoftAppCredentials(ConfigurationManager.AppSettings["MicrosoftAppId"],
ConfigurationManager.AppSettings["MicrosoftAppPassword"]);
var stateClient = new StateClient(botCredentials);
BotState botState = new BotState(stateClient);
BotData botData = new BotData(eTag: "*");
botData.SetProperty<string>("AccessToken", authResult.AccessToken);

// webchat is the channel id. Make sure it is same in the bot application when we get the user data
await stateClient.BotState.SetUserDataAsync("webchat", Session["botuserid"].ToString(), botData);
ViewBag.Message = "Your Token -" + authResult.AccessToken + " User Id - " + Session["botuserid"].ToString();
return View();
}

public ActionResult About()
{
ViewBag.Message = "Your application description page.";

return View();
}

public ActionResult Contact()
{
ViewBag.Message = "Your contact page.";

return View();
}
}
}
<p style="text-align: justify;">

Publish the Web Application to Azure.

Now let us go back to our Bot Application and update the messagecontroller.cs class.

</p>
using System.Net;
using System.Net.Http;
using System.Threading.Tasks;
using System.Web.Http;
using Microsoft.Bot.Builder.Dialogs;
using Microsoft.Bot.Connector;
using Microsoft.Bot.Builder.FormFlow;
using Bot_Application1.Models;
using System;
using Bot_Application1.Dialogs;
using System.Collections.Generic;
using System.Web;
using System.Net.Http.Headers;
using Newtonsoft.Json;
using Newtonsoft.Json.Linq;

namespace Bot_Application1
{
[BotAuthentication]
public class MessagesController : ApiController
{
/// <summary>
/// POST: api/Messages
/// Receive a message from a user and reply to it
/// </summary>
public async Task<HttpResponseMessage> Post([FromBody]Activity activity)
{
if (activity.Type == ActivityTypes.Message)
{
if (activity.Text.ToUpper() == "LOGIN")
{
ConnectorClient connector = new ConnectorClient(new Uri(activity.ServiceUrl));
Activity replyToConversation = activity.CreateReply();
replyToConversation.Recipient = activity.From;
replyToConversation.Type = "message";
replyToConversation.Attachments = new List<Attachment>();

List<CardAction> cardButtons = new List<CardAction>();
CardAction plButton = new CardAction()
{
// ASP.NET Web Application Hosted in Azure
// Pass the user id
Value = "http://azureauthwebapplication20170421122618.azurewebsites.net/Home/Login?userid=" + HttpUtility.UrlEncode(activity.From.Id),
Type = "signin",
Title = "Connect"
};

cardButtons.Add(plButton);

SigninCard plCard = new SigninCard("Please login to Office 365", new List<CardAction>() { plButton });
Attachment plAttachment = plCard.ToAttachment();
replyToConversation.Attachments.Add(plAttachment);
var reply = await connector.Conversations.SendToConversationAsync(replyToConversation);
}
else if (activity.Text.ToUpper() == "GETUSERS")
{
// Get access token from bot state
ConnectorClient connector = new ConnectorClient(new Uri(activity.ServiceUrl));
StateClient stateClient = activity.GetStateClient();
BotState botState = new BotState(stateClient);
BotData botData = await botState.GetUserDataAsync(activity.ChannelId, activity.From.Id);
string token = botData.GetProperty<string>("AccessToken");

var httpClient = new HttpClient();
httpClient.DefaultRequestHeaders.Add("OData-MaxVersion", "4.0");
httpClient.DefaultRequestHeaders.Add("OData-Version", "4.0");
httpClient.DefaultRequestHeaders.Accept.Add(new MediaTypeWithQualityHeaderValue("application/json"));
httpClient.DefaultRequestHeaders.Authorization = new AuthenticationHeaderValue("Bearer", token);

var retrieveResponse =
await httpClient.GetAsync("https://nishutrial.crm.dynamics.com/api/data/v8.1/systemusers?$select=fullname");
if (retrieveResponse.IsSuccessStatusCode)
{
var jRetrieveResponse =
JObject.Parse(retrieveResponse.Content.ReadAsStringAsync().Result);

dynamic systemUserObject = JsonConvert.DeserializeObject(jRetrieveResponse.ToString());

foreach (var data in systemUserObject.value)
{
Activity jsonReply = activity.CreateReply($"System User = {data.fullname.Value}");
await connector.Conversations.ReplyToActivityAsync(jsonReply);
}
}
else
{
Activity reply = activity.CreateReply("Failed to get users.\n\nPlease type \"login\" before you get users.");
await connector.Conversations.ReplyToActivityAsync(reply);
}
}
else
{
ConnectorClient connector = new ConnectorClient(new Uri(activity.ServiceUrl));
Activity reply = activity.CreateReply("# CRM BOT Instructions \n\nlogin --> Login to Office 365\n\ngetusers --> Get all System Users in CRM");
await connector.Conversations.ReplyToActivityAsync(reply);
}
}
else
{
HandleSystemMessage(activity);
}

var response = Request.CreateResponse(HttpStatusCode.OK);
return response;
}

private IDialog<LeadModel> MakeLuisDialog()
{
return Chain.From(() => new LUISDialog(LeadModel.BuildForm));
}

internal static IDialog<LeadModel> MakeRootDialog()
{
return Chain.From(() => FormDialog.FromForm(LeadModel.BuildForm));
}

private Activity HandleSystemMessage(Activity message)
{
if (message.Type == ActivityTypes.DeleteUserData)
{
// Implement user deletion here
// If we handle user deletion, return a real message
}
else if (message.Type == ActivityTypes.ConversationUpdate)
{
// Handle conversation state changes, like members being added and removed
// Use Activity.MembersAdded and Activity.MembersRemoved and Activity.Action for info
// Not available in all channels
}
else if (message.Type == ActivityTypes.ContactRelationUpdate)
{
// Handle add/remove from contact lists
// Activity.From + Activity.Action represent what happened
}
else if (message.Type == ActivityTypes.Typing)
{
// Handle knowing tha the user is typing
}
else if (message.Type == ActivityTypes.Ping)
{
}

return null;
}
}
}
<p style="text-align: justify;">

Publish the Bot to Azure.

Now let us test the Bot.

Go to – https://dev.botframework.com/bots

Open the Bot and click on Test.

Let us start the Chat.

On typing login the bot presents User with the Sign In Card. Click on Connect.

Sign in with your credentials.

Give permission to the app.

On successful sign-in –

Now type in getusers

It brings us all the System Users full name from our CRM Organization.

The extremely informative posts from which I learned about it

https://blogs.msdn.microsoft.com/tsmatsuz/2016/09/06/microsoft-bot-framework-bot-with-authentication-and-signin-login/

https://debajmecrm.com/2016/02/29/knowhow-how-to-execute-web-api-calls-to-microsoft-dynamics-crm-from-an-external-asp-net-web-application/

and following pluralsight training that helped in understanding OAuth and JWT concept.

https://www.pluralsight.com/courses/oauth2-json-web-tokens-openid-connect-introduction

Hope it helps..

Publishing Bot to Facebook Messenger


Let us continue with our previous posts on using Microsoft Bot Framework for writing a simple bot.

In our previous post, we published the bot app to Azure and also tested using Skype which is already configured.

In this post, we will be deploying the Bot to Facebook Messenger.

Sign in to Bot Developer Framework site

https://dev.botframework.com/

and open the bot application deployed.

Scroll down and we can see Facebook Messenger as one of the Channel available.

Click on Add.

Here we can see the guidelines and all the steps we need to do follow to configure the Facebook messenger

As a first step, we need to create a Facebook page for the bot

Click on the link and create a Facebook page

https://www.facebook.com/bookmarks/pages

Next step is to create a Facebook App for the bot

Click on the below link to create the Facebook app.

https://developers.facebook.com/quickstarts/?platform=web

Next step is to copy App ID and App Secret

Go to App Dashboard and copy these values. These values be used in the last step where we need to enter the credentials to authorize the app.

Next step is to enable the Messenger

Go to Dashboard and select Add Product.

Click on Get Started for Messenger.

Select the page from the dropdown and copy the token generated.

Next step is to set the Web Hook

Go to Messenger – Settings in Facebook App Dashboard.

And click on Setup
Webhooks.

Go back to Configure Facebook Messenger page and copy the url and token from there.

Copy these values and paste it to New Page Subscription. Check the required subscription fields and click on Verify and Save.

It will show the status as complete on successful verification.

Now as a last step we need to enter our credentials

  • Facebook Page Id –

i.e. 403898986632435

All other values we had already copied earlier. So just passt those values.

And Click on Resubmit.

Once the credentials are validated. Click on “I’m done with configuring Facebook Messenger”.

Click on Message Us to start the conversation.

Hope it helps..

Publishing Bot to Azure and adding it to Skype (Microsoft Bot Framework)


Let us continue with our previous posts on using Microsoft Bot Framework to create a simple bot application that creates a lead in CRM.

In this post, we will be publishing our Bot application to Azure and also test it on Skype. Skype is one of the channel already configured for us.

Open the Azure Portal (Create a free trial if you do not have an account)

https://portal.azure.com

Right click on the application and select Publish.

Select Microsoft Azure App Service as the publish target.

Create the app service

Validate the connection and on successful connection click on Publish.

The published Bot Application –

Now to register our bot go to bot framework developer site

https://dev.botframework.com/

Sign in and Click on Register a bot

Enter all the required details.

Here URL will be the Destination URL of Azure where the Bot Application was published.

Click on Manage Microsoft App ID and Password

Click on Generate an Microsoft App ID and password.

Save the password and app id which will be used for configuration later.

Enter the App Id and click on Register to register the Bot.

We will get the message “Bot created” on successful registration.

Back in our bot application, open its web.config and specify value for app id and password and republish the app.

Once it is published successfully, inside our bot we can click on Test to check the connection.

We’d get the message “Endpoint authorization succeeded”.

Scrolling down we can see two channels web and skype already configured.

Click on Add to Skype to add the bot as a contact to skype.

Click on “Add to Contacts”

Sign in with your Skype Credentials.

Launch Skype.

We can see the Bot added to our contacts.

This is how we can easily publish the Bot to azure and add it to Skype.

Hope it helps..

Using LUIS AI in Microsoft Bot Framework – Part 1


Let us continue with our previous posts on using Microsoft Bot Framework

In this post, we will add natural language processing to our Bot Application through LUIS i.e. Language Understanding Intelligent Service.

LUIS intercepts the User requests and converts it to comparable action for the bot.

The 3 most important aspects of LUIS Framework are

  • Intents – Identifies what actions you want your bot to take.
  • Entities – What things your bot is taking action on.
  • Utterances – Identifies phrases that links intents and entities.

Go to LUIS web site and Sign in

https://www.luis.ai/

After completing the sign up and finishing other details. Click on My apps link and select New App to create and register the app.

Provide the Name and culture as English and click on Create button.

Now as our app is created, we will now create the intent.

Go to the Dashboard of the app and select Create an intent.

Here we will create “Interest” as our first intent. Next, we define Utterances that points/associates to our intent.

Here we have defined want, interested and like as utterances associated to Interest.

So, for e.g. if we have following statement or response it will all point to the Interest intent.

  • I am interested to know about the product.
  • I want to know about the product
  • I like to know about the product.

Let us create a new Intent named Greeting and associate 2 utterances Hi and Hello to it.

Once we are done specifying our Intents the next important step is to Train and Test the application.

Select Train and Test and click on Train Application button.

Once the training is completed, we can make use of Interactive Testing interface to do the testing of our utterance and their score.

For e.g. hi utterance had full score i.e. 1 with Greeting intent and 0.19 and 0.13 with the other intent like Interest and None respectively.

Similarly, with “want” utterance we had .77 score for Interest intent.

Next, we test with meeska utterance for which we get the score of .66 with None Intent as this utterance is not associated to any of the intent we had defined nor it is understood by the application.

Now as we are done with testing let us publish it.

Once published, it will provide us with Endpoint URL.

We can append the text to the query string q in the above URL to get the JSON result. (as testing)


Now let us play around with Entity.

Select Entities link and click on Add custom entity button.

Here we are adding an entity named Product.

Now create one more intent that we will associate to this Entity Product named QueryProduct.

Let us add a new utterance, “do you have product1?” and here we will associate the product1 word with the Product entity.

To do so left click on the Product1 word, and select Product from the drop down.

This associates “Do you have [[xyz]]?” with Product entity.

We can quickly test it. Type any utterance like “Do you have x?” and in the result, we can see it being associated to QueryProduct1 intent with full score (1).

Now as we are done with all our configuration, training and testing, we need to train and publish the application again to have all the changes reflected.

In the next post we’d update our bot application to incorporate LUIS AI to it.

Hope it helps..

Configuring Live Assist (Preview) for Dynamics 365.


Let us see how we can configure Live Assist step by step.

First, go to Applications tab of the Dynamics 365 Administration Center.

Select Live Assist for Dynamics 365 and click on Manage.

Click on Accept to give permission to the app.

Select the Dynamics 365 Instance and provide your email id, accept the terms and conditions and click on Submit.

This configures the Live Assist on the specified Dynamics 365 Instance and also sends the email to the email id specified.

Once the configuration is done, we can see the new Live Assist section added in our Settings area.

There we can click on Admin URL of Live Assist for further configuration.

Clicking on it opens the Admin Center.

Click on Confirm and Authorize.

The Dashboard of the admin center.

The Get Started page.

Code Snippet that we can use to enable Live Assist in web site.

Live Assist adds a new panel on the right inside CRM.

To test it we can make use of Demo Site provided along with Live Assist.

The agent within CRM can click on Conversation Icon and “Grab a chat” to start conversation.

Now suppose we want to configure our CRM Portal to use it. For this we need to copy the code snippet provided earlier. Go to the Header web template of our Web Site and paste the JavaScript code to our Header’s source code.

This enables Live Assist in the portal.

Communication between the CRM user and the Portal user.

The helpful links and video

https://neilparkhurst.com/2017/04/09/cafex-live-assist-my-initial-install-with-usd/

https://blogs.technet.microsoft.com/lystavlen/2017/03/16/live-assist-for-dynamics-365-first-look/

Hope it helps..

Setting Regarding of a record in Automatic Record Creation and Update Rules in Dynamics 365


Hi,

While implementing a scenario i.e. automatic case creation on phone call create using Automatic Record Creation and Updating Rules, we found that whenever we were setting the Regarding Object in the Phone Call activity, the case record was not getting created.

Create Case Rule Item –

Creating a Phone Call record using Case as Regarding object.

Workflow ran but the case record was not created.

Then we created phone call activity record without setting the regarding object. This time workflow ran and created the case record.

Basically, the workflow creates the case record and updates the Regarding Object in the Phone call record with this newly created case record.

However, if we check the Official documentation

https://www.microsoft.com/en-us/dynamics/crm-customer-center/set-up-rules-to-automatically-create-or-update-records-in-dynamics-365-customer-service.aspx#bkmk_RuleAndQueues

we have this mentioned

However, in our case we created a phone call record with case as regarding object and had case as the entity selected in the Create Record step, in this case also the Action were not executed.

Hope it helps..

Unknown Error or Resource not found for the segment ‘msdyn_FpsAction’ in Schedule Board in Field Service in Dynamics 365.


Hi,

Recently we configured the portal trial instance and installed Partner Field Service portal in it .

However, while trying to access Field Service à Schedule Board, we were getting the below errors

Eventually it turned out that the issue was caused because of the certain processes being in draft state.

The post which helped in fixing this issue

https://glinks.co.uk/2017/01/06/field-services-schedule-board-unknown-error/

Hope it helps..

Configure Product Recommendations using Recommendations API in Dynamics 365


For configuring Product Recommendations first we need to enable the preview –

Go to Settings – Administration – System Settings – Previews

Select Yes and Click on OK.

As a next step, we need to create Cognitive Services for Recommendation API and connect it to CRM.

Go to Portal

https://portal.azure.com

Search and select Cognitive Services Accounts

Click on Add

Select Recommendation API and provide other details and click on Create.

From Overview, note down the Endpoint which will be used to configure the connection in CRM.

From Keys, copy value of the Key which will be used for configuring connection to CRM.

In CRM, go to Settings – Administration and click on Azure Machine Learning Recommendation Service Configuration.

Specify the value for the URL and Key we had noted down earlier, save the record and click on Test Connection to test the connection.

On Successful connection, we’d see Success message for Last Connection Status. Click on Activate to enable the connection.

Now we need to define\build the model for recommendations. For this go to Settings – Product Catalog and click on Product Recommendations.

We’d see a recommendation model with default values

The model will have Basked Data Entities already defined. We can edit\add new\ delete these existing configuration records for Basked Data Entities. Basked Data Entities recommendations are based on which products appear together.

For e.g. in below Opportunity record we can see 27 inch and 12 inch monitor opportunity products appearing together. It will look for all such line items records.

Similarly we have recommendation entities records configured which we can update.

Once done with the configuration, we need to click on Build Model Version to build the model.

It will create a corresponding model version record.

We can check its progress by refreshing it.

Here the model that we had defined has successfully build and it took around 6 minutes.

We can click on the Model Version to open the record to get the further details.

Next step would be to check the recommendations. For this click on Test Recommendations.

Pop up opens wherein we can select the Products and model version and click on Show Result to see what are the product recommendations.

Once satisfied with the test result, click on Activate to enable the recommendations.

We might get the below message in case we do not have good enough data in our system.

To see it in action, open an existing opportunity record , go to product sub grid and select a product and select Suggest Products.

A dialog box opens up that shows the Cross-Sell products and other details.

Get all the details here

https://technet.microsoft.com/library/56b35229-72f8-46ca-bebf-eae023f633c2.aspx

Hope it helps..
