Sample Code to consume UNData API using JavaScript

Sharing a sample code that can be used to consume UNData API

http://data.un.org/Host.aspx?Content=API

The below code fetches the population data for country India.

Sample Code


var xmlHttp;
// creatng the xmlHttp object
xmlHttp = new ActiveXObject("Microsoft.XMLHTTP");
// Calling the web service using post and true means asynchronous call
xmlHttp.open("POST", "http://data.un.org/WS/NSIEstatV20Service.asmx", false);

// Setting the request header to let the web service find the soap request we would be sending
xmlHttp.setRequestHeader("Content-Type", "text/xml; charset=utf-8");

xmlHttp.setRequestHeader("SOAPAction", "http://ec.europa.eu/eurostat/sri/service/2.0/extended/GetCompactData");

var soapRequest = "<!--?<span class="hiddenSpellError" pre="" data-mce-bogus="1"-->xml version='1.0' encoding='utf-8'?>"+
"<soap:Envelope xmlns:soap='http://schemas.xmlsoap.org/soap/envelope/' xmlns:xsi='http://www.w3.org/2001/XMLSchema-instance' xmlns:xsd='http://www.w3.org/2001/XMLSchema'>"+
"<soap:Body>"+
"<GetCompactData xmlns='http://ec.europa.eu/eurostat/sri/service/2.0/extended'>"+
"<Query>"+
"<message:QueryMessage xsi:schemaLocation='http://ec.europa.eu/eurostat/sri/service/2.0/SDMXMessage.xsd http://ec.europa.eu/eurostat/sri/service/2.0/%20SDMXMessage.xsd' xmlns:generic='http://www.SDMX.org/resources/SDMXML/schemas/v2_0/generic' xmlns:message='http://www.SDMX.org/resources/SDMXML/schemas/v2_0/message' xmlns:query='http://www.SDMX.org/resources/SDMXML/schemas/v2_0/query' xmlns:xsi='http://www.w3.org/2001/XMLSchema-instance'>"+
"<message:Header>"+
"<message:ID>onh14833545733929527</message:ID>"+
"<message:Test>false</message:Test>"+
"<message:Prepared>2017-01-01</message:Prepared>"+
"<message:Sender id='online-help' />"+
"</message:Header>"+
"<message:Query>"+
"<query:DataWhere>"+
"<query:And>"+
"<query:Dimension id='INDICATOR'>SP_POP_TOTL</query:Dimension>"+
"<query:Dimension id='AGE'>_T</query:Dimension>"+
"<query:Dimension id='SEX'>_T</query:Dimension>"+
"<query:Dimension id='LOCATION'>_T</query:Dimension>" +
"<query:Dimension id='REF_AREA'>DEU</query:Dimension>" +
"<query:Dimension id='SCENARIO'>H</query:Dimension>"+
"<query:Time>"+
"<query:StartTime>2014-01-02</query:StartTime>"+
"<query:EndTime>2017-01-02</query:EndTime>"+
"</query:Time>"+
"<query:Dataflow>DF_UNDATA_WPP</query:Dataflow>"+
"</query:And>"+
"</query:DataWhere>"+
"</message:Query>"+
"</message:QueryMessage>"+
"</Query>"+
"</GetCompactData>"+
"</soap:Body>" +
"</soap:Envelope>";

xmlHttp.send(soapRequest);
var xmlDoc = jQuery.parseXML(xmlHttp.responseText);
var popValue = xmlDoc.getElementsByTagName('ns1:Obs')['0'].attributes['OBS_VALUE'].nodeValue;
alert("Total Population " + popValue);

Output


<?xml version="1.0" encoding="utf-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:xsd="http://www.w3.org/2001/XMLSchema">
<soap:Body><GetCompactDataResponse
xmlns="http://ec.europa.eu/eurostat/sri/service/2.0/extended">
<GetCompactDataResult>
<CompactData
xmlns:ns1="urn:sdmx:org.sdmx.infomodel.datastructure.DataStructure
=UNSD:DSD_WPP_UNDATA(1.0):ObsLevelDim:TIME_PERIOD"
xmlns="http://www.SDMX.org/resources/SDMXML/schemas/v2_0/message"
xmlns:common="http://www.SDMX.org/resources/SDMXML/schemas/v2_0/common"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:xml="http://www.w3.org/XML/1998/namespace"><Header>
<ID>DF_UNDATA_WPP</ID><Test>false</Test><Prepared>2017-01-06T08:25:46
</Prepared>
<Sender id="1B0">
<Name xml:lang="en">United Nations Statistics Division</Name>
<Contact><Email>statistics@un.org</Email></Contact></Sender>
<KeyFamilyRef>DSD_WPP_UNDATA</KeyFamilyRef><KeyFamilyAgency>UNSD
</KeyFamilyAgency><DataSetAgency>UNSD</DataSetAgency>
<DataSetID>DF_UNDATA_WPP_1B0_2017-01-06T082546</DataSetID>
<DataSetAction>Information</DataSetAction>
<Extracted>2017-01-06T08:25:46</Extracted>
<Source xml:lang="en">
United Nations Population Division World Population Prospects</Source>
</Header>
<ns1:DataSet DATASET_NAME="World Population Prospects"
DATASET_SOURCE="United Nations Population Division"
DATASET_DESC="The United Nations World Population Prospects contains estimates and projections for every country in the world, including estimates and projections of demographic indicators such as birth rates, deaths rates, infant mortality rates and life expectancy." UNDATA_LASTUPDATE="20 Aug 2013" UNDATA_NEXTUPDATE="2015 release" METADATA="http://esa.un.org/unpd/wpp/index.htm"><ns1:Series AGE="_T" FREQ="A" INDICATOR="SP_POP_TOTL" LOCATION="_T" SEX="_T" REF_AREA="DEU" SCENARIO="H"><ns1:Obs TIME_PERIOD="2015" OBS_VALUE="83178.615" UNIT="NUMBER" UNIT_MULT="3" TIME_SPAN="2015" /></ns1:Series></ns1:DataSet></CompactData></GetCompactDataResult></GetCompactDataResponse></soap:Body></soap:Envelope>

Hope it helps.

Sample code to consume UNData API in C#

Hi,

Recently we were working on an application that had to fetch country specific details. For this we used the UNData API.

http://data.un.org/Host.aspx?Content=API

We can make use of SDMX Browser in helping us to write a query

http://data.un.org/SdmxBrowser/start

Create a console app\windows application and add web reference to the following web service

http://data.un.org/WS/NSIEstatV20Service.asmx

Below is the sample C# Code


string queryMsg = @"<message:QueryMessage
xsi:schemaLocation='http://ec.europa.eu/eurostat/sri/service/2.0/SDMXMessage.xsd
http://ec.europa.eu/eurostat/sri/service/2.0/%20SDMXMessage.xsd'
xmlns:generic='http://www.SDMX.org/resources/SDMXML/schemas/v2_0/generic'
xmlns:message='http://www.SDMX.org/resources/SDMXML/schemas/v2_0/message'
xmlns:query='http://www.SDMX.org/resources/SDMXML/schemas/v2_0/query'
xmlns:xsi='http://www.w3.org/2001/XMLSchema-instance'>
<message:Header>
<message:ID>onh14833545733929527</message:ID>
<message:Test>false</message:Test>
<message:Prepared>2017-01-01</message:Prepared>
<message:Sender id='online-help'/>
</message:Header>
<message:Query>
<query:DataWhere>
<query:And>
<query:Dimension id='INDICATOR'>SP_POP_TOTL</query:Dimension>
<query:Dimension id='AGE'>_T</query:Dimension>
<query:Dimension id='SEX'>_T</query:Dimension>
<query:Dimension id='LOCATION'>_T</query:Dimension>
<query:Dimension id='REF_AREA'>IND</query:Dimension>
<query:Time>
<query:StartTime>2014-01-02</query:StartTime>
<query:EndTime>2017-01-02</query:EndTime>
</query:Time>
<query:Dataflow>DF_UNDATA_WPP</query:Dataflow>
</query:And>
</query:DataWhere>
</message:Query>
</message:QueryMessage>";
NSIEstatV20Service service = new NSIEstatV20Service();
System.Xml.XmlDocument queryMessageDocument = new XmlDocument();
queryMessageDocument.LoadXml(queryMsg);
System.Xml.XmlNode queryMessage = queryMessageDocument.DocumentElement;
var result = service.GetCompactData(queryMessage);
MessageBox.Show(result.InnerXml);

The output

The query here basically returns the Total population of India

Hope it helps..

Code to upload multiple attachments to SharePoint Folder using Client Object Model


public static void UploadDocument(
string siteURL,
string documentListName,
string documentListURL,
string documentName,
byte[] documentStream,
string folderName,
string invoiceId)
{
using (var clientContext = new ClientContext(siteURL))
{
// Get Document List
var documentsList = clientContext.Web.Lists.GetByTitle(documentListName);

// check if folder already exists else create folder

if (!FolderExists(clientContext.Web, documentListName, folderName))
{
var info = new ListItemCreationInformation();
info.UnderlyingObjectType = FileSystemObjectType.Folder;
info.LeafName = folderName.Trim();
var newItem = documentsList.AddItem(info);
newItem["Title"] = folderName;
newItem.Update();
clientContext.ExecuteQuery();
}

var fileCreationInformation = new FileCreationInformation();

// Assign to content byte[] i.e. documentStream
fileCreationInformation.Content = documentStream;

// Allow owerwrite of document
fileCreationInformation.Overwrite = true;

// Upload URL
fileCreationInformation.Url = siteURL + documentListURL + folderName + "/" + documentName;
var uploadFile = documentsList.RootFolder.Files.Add(fileCreationInformation);

// Update the metadata for a field having name "DocType"
uploadFile.ListItemAllFields["Invoice_x0020_Id"] = invoiceId;

uploadFile.ListItemAllFields.Update();
clientContext.ExecuteQuery();
}
}


public static bool FolderExists(Web web, string listTitle, string folderUrl)
{
var list = web.Lists.GetByTitle(listTitle);
var folders = list.GetItems(CamlQuery.CreateAllFoldersQuery());
web.Context.Load(list.RootFolder);
web.Context.Load(folders);
web.Context.ExecuteQuery();
var folderRelativeUrl = string.Format("/{0}/{1}", list.RootFolder.Name, folderUrl);
return Enumerable.Any(folders, folderItem => (string)folderItem["FileRef"] == folderRelativeUrl);
}

Extracting Attachment from InfoPath form using C#

The sample code for extracting attachment from submitted InfoPath form

var lstTimeSheet = new List<RelatedTimesheet>();
 foreach (var timeSheet in invoiceFormData.Summary.Timesheet)
 {
 if (timeSheet.Attachment != null)
 {
 var tSheet = new RelatedTimesheet();
 var b = timeSheet.Attachment;
 var nameBufferLen = b[20] * 2;
 var fileNameBufffer = new byte[nameBufferLen];
 for (var i = 0; i < nameBufferLen; i++)
 {
 fileNameBufffer[i] = b[24 + i];
 }

 var charFileName = Encoding.Unicode.GetChars(fileNameBufffer);
 var fileName = new string(charFileName);
 tSheet.FileName = fileName.Substring(0, fileName.Length - 1);

 var fileContent = new byte[b.Length - (24 + nameBufferLen)];
 for (var i = 0; i < fileContent.Length; i++)
 {
 fileContent[i] = b[24 + nameBufferLen + i];
 }

 tSheet.Attachment = fileContent;
 lstTimeSheet.Add(tSheet);
 }
 }

public class RelatedTimesheet
{
 public string FileName { get; set; }
 public byte[] Attachment { get; set; }
}

Split List into equal parts in C#

Hi,

Had a requirement to split a List in 3 smaller lists.

For e.g. if a list has 13 different elements.

It has to split into 3 list containing 5, 5 and 3 elements in it.

The helpful post

http://stackoverflow.com/questions/3892734/split-c-sharp-collection-into-equal-parts-maintaining-sort

Hope it helps !

Calling a Windows Authenticated WCF Service in a Plugin in CRM

Hi,

Suppose we need to call the service created here in our plugin

https://nishantrana.me/2014/09/05/configure-a-wcf-service-for-windows-authentication/

As plugin don’t have configuration file, we need to specify binding information in Code.

The sample code to call the WCF Service by passing Network Credentials


private static void CallWCFService()
{
BasicHttpBinding binding = new BasicHttpBinding();
binding.Security.Mode = BasicHttpSecurityMode.TransportCredentialOnly;
binding.Security.Transport.ClientCredentialType = HttpClientCredentialType.Windows;

// Specify the endpointAddress
EndpointAddress endpointAddress = new EndpointAddress(new Uri("http://servername:port/Service1.svc"));

ServiceReference1.Service1Client client = new ServiceReference1.Service1Client(binding, endpointAddress);
if (client.ChannelFactory.Credentials != null)
client.ChannelFactory.Credentials.Windows.ClientCredential = new System.Net.NetworkCredential("username", "password", "domain");
if (client.ClientCredentials != null)
client.ClientCredentials.Windows.AllowedImpersonationLevel = System.Security.Principal.TokenImpersonationLevel.Delegation;
MessageBox.Show(client.GetData(1));
}

Hope it helps ..
