Link Entity, Query Expression and FetchXml Wizard

Let say we need to make use of CrmService to give us the name of the opportunity where owner’s fullname=’someName’;

Name is an attribute of Opportunity Entity.
FullName is an attribute of SystemUser Entity.

So we need to make use of LinkEntity class over here to link from opportunity entity to systemuser entity.

Now let’s use queryExpression for the same.



But plzzzz don’t write it yourself, use FetchXmlBuilder to write it for you.
Plzz understand it and download it from this link

http://www.stunnware.com/crm2/topic.aspx?id=FindingData6
(The best site for all the CrmDevelopers)

This is how the queryExpression code will look like



QueryExpression query = new QueryExpression();

query.EntityName = “opportunity”;

ColumnSet columns = new ColumnSet();
columns.Attributes = new string[] { “name” };
query.ColumnSet = columns;

LinkEntity linkEntity1 = new LinkEntity();
linkEntity1.JoinOperator = JoinOperator.Natural;
linkEntity1.LinkFromEntityName = “opportunity”;
linkEntity1.LinkFromAttributeName = “owninguser”;
linkEntity1.LinkToEntityName = “systemuser”;
linkEntity1.LinkToAttributeName = “systemuserid”;

linkEntity1.LinkCriteria = new FilterExpression();
linkEntity1.LinkCriteria.FilterOperator = LogicalOperator.And;

ConditionExpression condition1 = new ConditionExpression();
condition1.AttributeName = “fullname”;
condition1.Operator = ConditionOperator.Equal;
condition1.Values = new object[] { “Nishant Rana” };

linkEntity1.LinkCriteria.Conditions = new ConditionExpression[] { condition1 };

query.LinkEntities = new LinkEntity[] { linkEntity1 };

Now say we have a requirement where we need

The name of all the opportunity along with the fullname of the owner.

Let’s try doing it with a queryExpression class and using the FetchXmlBuilder.

This is the code which we’ll get

………….

LinkEntity linkEntity1 = new LinkEntity();

linkEntity1.JoinOperator = JoinOperator.Natural;

linkEntity1.LinkFromEntityName = “opportunity”;

linkEntity1.LinkFromAttributeName = “owninguser”;

linkEntity1.LinkToEntityName = “systemuser”;

linkEntity1.LinkToAttributeName = “systemuserid”;

//You have specified columns for this link-entity. This is not supported in query expressions



This means it’s not possible using queryExpression

So in this case we need to make use of FetchXml to fetch use the fullname of the owning user.

The fetch xml looks like this

string fetchXml = @”
<fetch mapping=””logical”” count=””50″”>
<entity name=””opportunity””>
<attribute name=””name”” />
<link-entity name=””systemuser”” from=””systemuserid”” to=””owninguser””>
<attribute name=””fullname”” />
</link-entity>
</entity>
</fetch>”;

// Finally the code

CrmService service = new CrmService();
service.Credentials = System.Net.CredentialCache.DefaultCredentials;
string fetchXml = @”
<fetch mapping=””logical”” count=””50″”>
<entity name=””opportunity””>
<attribute name=””name”” />
<link-entity name=””systemuser”” from=””systemuserid”” to=””owninguser””>
<attribute name=””fullname”” />
</link-entity>
</entity>
</fetch>”;
String result = service.Fetch(fetchXml);



Now the only problem is we need to parse the xml on our own.

We can use something like this

if this is the result we are receiving

<resultset morerecords=”0″><result><new_id>GP0677</new_id></result></resultset>

to fetch the new_id we can do this

XmlDocument doc = new XmlDocument();
doc.LoadXml(result);
XmlNodeList xnodlist=doc.GetElementsByTagName(“
new_id”);
XmlNode xnodRoot=xnodlist.Item(0);
string val=xnodRoot.InnerText;





Bye.



Using ALLColumns() in Dynamics CRM

Hi,

To retireve the values for all the attributes of an entity we can make use of ALLColumns ,

CrmService service=new CrmService();

service.Credentials = System.Net.CredentialCache.DefaultCredentials;

QueryExpression query = new QueryExpression();

query.EntityName = EntityName.new_entityname.ToString();

query.ColumnSet=new AllColumns();

BusinessEntityCollection entities= service.RetrieveMultiple(query);

for(int i=0;i<entities.BusinessEntities.Length;i++)

{

new_entityname nEntity=(new_entityname) entities.BusinessEntities[i];

Response.Write(“<b>”+nEntity.new_id+” -></b>”);

Response.Write(“<i>” + nEntity.createdby.name + ” –></i>”);

}

}

Or by using QueryByAttribute

It can be used when our query is very simple i.e. multiple equals conditions that are combined using AND.

But remember it doesn’t support OR
QueryByAttribute myQuery=new QueryByAttribute();
myQuery.ColumnSet=new AllColumns();
myQuery.EntityName=EntityName.opportunity.ToString();

    // Find all the opportunities with topic name test1 and city as Redmond
myQuery.Attributes=new string[]{“name”,”address1_city”};
myQuery.Values=new string[]{“Test1″,”Redmond”};
BusinessEntityCollection retrieved=service.RetrieveMultiple(myQuery);

Bye

Query for finding Team and it’s member in MS DYNAMICS CRM

Hi,

We can use this query to retrieve different teams and the users belonging to that team within Microsoft Dyanmics CRM

Select FT.name TeamName,FSU.Fullname UserName, FSU.Systemuserid from
dbo.FilteredSystemUser FSU
inner Join
dbo.FilteredTeamMembership FTM
on FSU.Systemuserid = FTM.Systemuserid
Inner join  dbo.FilteredTeam FT
on FT.TeamID = FTM.TeamID
ORDER BY FT.NAME

Bye

Hiding or disabling elements in Microsoft Dynamics CRM 3.0

Aim : To disable the close opportunity menu item from the Actions Menu for Opportunity form.

Put the following code in the Form_Load script of the Opportunity form

document.getElementById(‘_MIcomplete’).Style=”display:none” ;


Put the id of the menu item there
To get the id name for any particular menu item

  • step 1- open the opportunity form in crm.

  • step 2- press ctrl+N to open the same form in a new window.

  • step 3- right click go to view source and find the id of the required element.

Same thing we can do for buttons added through isv.config as well as other elements

ISV_New_1_199_Billing.style.display = “none” ;

Bye

Calling Asp.NET web service from form onLoad in CRM

This is the code we can make use for calling ASP.NET webservice in form onLoad javascript event handler of our Entity in Microsoft CRM.

This example calls the simple Hello World service and assigns the value returned (i.e. “Hello World”) to a field in the entity form

xmlHttp=new ActiveXObject(“Microsoft.XMLHTTP”);

xmlHttp.open(‘post’, ‘http://localhost/WebService1/Service1.asmx/HelloWorld’, false);

xmlHttp.send();

var xmlDoc=xmlHttp.responseXML;

var responseElement=xmlDoc.getElementsByTagName(“string”)[0];

var exch=responseElement.firstChild.nodeValue;

crmForm.all.address1_name.DataValue=exch ;

return false;

Check this link for more information

https://nishantrana.wordpress.com/2007/10/18/calling-aspnet-webservice-from-javascript-ajax/

Bye

Refresh CRM form from third-party applications

http://support.microsoft.com/default.aspx/kb/821669

Code to put in the javascript of our custom page

function window.onunload()
{
window.opener.location.reload();
window.close();
}

But the thing with the code is that it only works when we deploy the page in the same server where our Crm is deployed.

When i had deployed the page in my machine, the page wasn’t refreshing but when i deployed the same page where the crm is deployed everything was working perfectly fine.

I think in the previous case because of the cross-domain issue i guess there were problems.

One more thing,  to assign values to attributes in our Crm Form from our isv page we can make use of familiar syntax

window.opener.document.crmForm.all.new_totalbilling.DataValue=parseInt(//value );

parseInt – if the crm attribute is of numeric type

alert(window.parent.document.all.crmForm.all.name.DataValue);

Bye

Finding shared records in CRM

To find all the records(say lead)  shared with any particular user we can make use of following query

It will return us all records(lead) shared with the user directly( i.e. through Action–>Sharing and user)

select  fl.subject

from
PrincipalObjectAccess poa , FilteredLead fl, FilteredSystemUser fsu
where
poa.ObjectTypeCode = 4
and poa.ObjectId = fl.leadid
and poa.PrincipalId = fsu.systemuserid
and fsu.domainname=SYSTEM_USER

// fsu.fullname=’name of user’

And to get the records shared with the user indirectly (i.e. through Action–>Sharing and Team (user belongs to that team)

select  fl.subject
from
FilteredLead fl,  PrincipalObjectAccess poa,  FilteredTeam ft
where
poa.ObjectTypeCode = 4

and poa.ObjectId =fl.leadid
and poa.PrincipalId = ft.teamid and

fl.owneridname not in (select fullname from filteredsystemuser
where domainname=SYSTEM_USER)
and
ft.teamid  in (select ft.teamid from filteredteammembership fm
, filteredsystemuser fsu, filteredteam ft
where fm.systemuserid=fsu.systemuserid and
ft.teamid=fm.teamid
and fsu.domainname=SYSTEM_USER
)

Bye

Making value in one lookup depended on value of another lookup.

Making value in one lookup depended on value of another lookup in Microsoft CRM. Say we have created 2 custom entities Categories and Skill. Skill entity has category lookup field which relates it to that category.(Added a relationship between them)Than created few records for both the entities. After that we have added that entities to the third entity where they’ll appear as LookUp.

Now we want the value of Skill lookup to be dependent value selected on Resource(Category) LookUp.


Resource can have following values


Now if Datawarehousing is selected than

we want to show Analysis and SSAS in the Skill lookup


To accomplish this we will write the following code in the OnChange event of Resource Lookup

// Making the skill id lookup null whenver a new values is selected for reesource

crmForm.all.new_skillid.DataValue=null;

crmForm.all.new_skillid.disabled = false;

// getting the value of selected resource

var ar=new Array();

ar=crmForm.all.new_resourceid.DataValue;

var rID = ar[0].id;

// Changing the display of skillid lookup so that only skill belonging to particular rID should appear

crmForm.all.new_skillid.lookupbrowse=1;

// in the additionalparams for the skill id attribute we will specify the fetch xml query // e.g. select * from new_categoryskill (name of our custom skill entity) where new_categoryofskillid = rid

crmForm.all.new_skillid.additionalparams = “fetchXml=<fetch mapping=’logical’ ><entity name=’new_categoryskill’><all-attributes/><filter type=’and’><condition attribute=’new_categoryofskillid’ operator=’eq’ value='” + rID + “‘/></filter></entity></fetch>”;

To get the fetchXml query what we can do over here is

http://ronaldlemmen.blogspot.com/2006/11/using-advanced-find-for-fetchxml.html

We will go to our skill entity form and run an advancedfind query against it (giving the appropriate condition for which we want the fetch xml)

Now pressing CTRL+N open it in a new window Now in URl replace everything with the following line

javascript:prompt(“my%20query:”,%20resultRender.FetchXml.value);

Press Ok to the dialog that appears and it opens a prompt window from where we can copy our fetch xml and modify it accordingly.


Using ISV.config to access field values in CRM

First of all open your isv.config file ( found at <installation path\_Resources\isv.config e.g. C:\Program Files\Microsoft CRM\CRMWeb\_Resources”

Here we are adding buttons in the form toolbar for opportunity, inside the isv.config file (Plzz take it’s backup)

Add the following

<Entity name=”opportunity”>

<ToolBar ValidForCreate=”0″ ValidForUpdate=”1″>

<Button Title=”MyBtn1″ Icon=”/_imgs/ico_18_debug.gif”

Url=”http://default.aspx” PassParams=”1″ WinParams=”” WinMode=”0″ AvailableOffline=”false” />

<Button Title=”my button” ToolTip=”Advanced Mail Merge” Icon=”url” Client=”Web, Outlook”

JavaScript=

var n=crmForm.all.name.DataValue;

var objectID=crmForm.ObjectId;

window.open(‘http://Default.aspx?name=’+n+’&oId=’+objectID)”

/>

</ToolBar>

</Entity>

In the above code we have created two button.

First button makes use of URL and passParam attribute.

When we set passParam as 1 then objectid( id of the record), object name and object type code are passed to url specified as query string.

The thing here is that in our custom web page we can only get the id and the type of entity.

What if we want values of other form fields.

Well in this case we can make use of JavaScript attribute.This attribute will override the Url attribute if in case both of them are defined.In the above code we are attaching the name value of opportunity in the query string.

One more thing to get the current record’s primary key i.e. say opportunity id for opportunity we’ll use crmForm.ObjectId

We can even user window.opener object in javascript of our isv custom page.

Chk this

https://nishantrana.wordpress.com/2007/10/13/refresh-crm-form-from-third-party-applications/

Bye

Finding Lead records that have an associated activity with them

Here in the query one more condition is added which is when the Rating is Hot.

select leadqualitycodename,* from filteredlead As fl inner join dbo.FilteredActivityParty as fap
ON fl.leadid=fap.partyid
and fl.leadid=‘yourleadid’ and leadqualitycodename=‘Hot’
